128
2024-12-02 13:29:25
2m³A020E electric LHD of HOT adopts electric motor drive, rubber pneumatic tires, front and rear four-wheel drive, central articulation, front bucket and front unloading loading equipment, and adopts hydraulic mechanical transmission device (including hydraulic torque converter and gearbox) All are imported from abroad) wheel side planetary reducer and wet multi-disc brakes and other technologies. A020E electric scraper is suitable for stage caving method, empty field method, room-pillar method, non-pillar subsection mining and roadway excavation, as well as auxiliary operations such as working road leveling and material transportation.
113
2024-12-02 13:28:25
The power system of 1m³A010E electric LHD is driven by an AC 380V, 45KW electric motor. Hydraulic control variable pump-fixed motor-transmission gear box-front and rear axle-four rubber wheels drive. After adopting slewing bearing connection, the frame swings. The reeling system adopts hydraulic control operation and the pressure of rewinding and unwinding is stable. Use dedicated scraper cables. The working system adopts pilot hydraulic control operation, which makes the operation of the scraper easier, more efficient, and has a low failure rate. The emergency parking brake adopts friction disc brake, spring brake, hydraulic pressure releases the brake, and immediately brakes after sudden power failure, which is safe and reliable.
133
2024-12-02 13:27:14
0.6m³A006E Electric LHD is mainly used for shoveling and transporting blasted ore and rubble in underground mines. It can also be used for railway, highway and tunnel engineering. It is especially suitable for poor working conditions, narrow, low and muddy working sites operation surface.
117
2024-12-02 13:25:46
1m³A010D diesel LHD of HOT is a four-wheel drive, central articulated, front-loading and forward-discharging scraper powered by a diesel engine. This machine adopts variable pump-variable motor-transmission gear box-front and rear axle-four rubber wheels for transmission. The frame swings after the slewing bearing is connected. The working system adopts pilot hydraulic control operation, which makes the operation of the scraper easier, more efficient, and has a low failure rate. The emergency parking brake adopts friction disc brake, spring brake, hydraulic pressure releases the brake, and immediately brakes after sudden power failure, which is safe and reliable.
119
2024-12-02 13:25:30
3m³ A030D diesel LHD of HOT is driven by water-cooled diesel engine, rubber pneumatic tires, front and rear four-wheel drive, central articulation, front bucket and front unloading loading equipment, using hydromechanical transmission wheel side planetary reducer and wet multi-disc Brakes and other technologies. Diesel LHDs are suitable for stage caving method, open field method, room-pillar method, non-pillar subsection mining and roadway excavation, as well as auxiliary operations such as road leveling and material transportation.
119
2024-12-02 13:23:03
A006D diesel LHD of HOT is mainly used for underground operations in mines. It can also be used for railway, highway and tunnel engineering. It is especially suitable for poor working conditions, narrow working sites, low and muddy working surfaces.
132
2024-12-02 11:21:19
It supports free disassembly on the roof. After disassembly, the height of the LHD is only 1.7m. It has stronger adaptability to underground environment and is specially designed for underground shovel transport, which is very suitable for working in low underground roadway.
